WIFI 8 kVt o'chirilgan tarmoq inverteri bilan MPPT

Ochiq tarmoq zaryadlovchi inverteri tarmoqdan tashqari quyosh energiyasi tizimlarida muhim komponent hisoblanadi. Invertorlar quyosh panellari tomonidan ishlab chiqarilgan yoki batareyalarda saqlanadigan doimiy (to'g'ridan-to'g'ri oqim) elektr energiyasini maishiy texnika va elektronikani quvvatlantirish uchun ishlatilishi mumkin bo'lgan AC (o'zgaruvchan tok) elektr energiyasiga aylantiradi.

Mahsulotni tanishtirish

Mahsulotlar tavsifi

O'chirilgan tarmoq inverteri

Foydalanuvchilar o'zlarining barcha quvvat ehtiyojlarini mustaqil ravishda ishlab chiqarish orqali o'zini o'zi ta'minlashga erishishlari mumkin.

Uy egalari quyosh nuri yoki shamolning eng yuqori cho'qqisi bo'lmagan soatlarda elektr energiyasi ishlab chiqarishi va uni keyinchalik foydalanish uchun saqlashi mumkin.

Ko'pgina hollarda, o'rnatish, ayniqsa, chekka hududlarda, tarmoqqa ulanishga nisbatan ancha tejamkor bo'lishi mumkin.

Ochiq tarmoq tizimlari odatda an'anaviy tarmoqqa ulangan tizimlarga qaraganda kamroq texnik xizmat ko'rsatishni talab qiladi.

Mahsulot parametri

ModeI	GD3024ML	GD3024JMH	GD5548JMH	GD11048MHB
PV kirish
PV maksimal kirish quvvati	1500W	3500W	5500W	5500W+5500W
MPPT kuchlanish diapazoni	30 ~ 115 Vdc	120 ~ 430 Vdc	120 ~ 430 Vdc	120 ~ 450 Vdc
PV zaryadlash usuli	MPPT*1	MPPT*1	MPPT*1	MPPT*2
Maksimal PV kirish kuchlanishi	145 Vdc	450 Vdc	450 Vdc	450 Vdc
Maksimal PV zaryadlash oqimi	60A	100A	100A	80A+80A
Batareya
Nominal kuchlanish	24Vdc	24Vdc	48Vdc	48Vdc
Doimiy kuchlanish zaryadlash kuchlanishi (ixtiyoriy)	28,2V to'g'ridan-to'g'ri oqim	28,2V to'g'ridan-to'g'ri oqim	56,4 Vdc	56,4 Vdc
Suzuvchi zaryad kuchlanishi (ixtiyoriy)	27Vdc	27Vdc	54Vdc	54Vdc
AC kirish
Bosqich	L+N+PE
Nominal kuchlanish	208/220/230/240VAC
Voltaj diapazoni	154-264VAC±3V(Oddiy rejim)185-264VAC±3V(UPS rejimi)
Chastota diapazoni	50Hz/60Hz (moslashuvchan)
AC chiqishi
Nominal quvvat	3000W	3000W	5500W	11000W
Maksimal quvvat	6000VA	6000VA	10000VA	20000VA
Chiqish kuchlanishi (AC)	208/220/230/240VAC±5%
Maksimal AC zaryadlash oqimi	60A	60A	100A	80A+80A
Chiqish chastotasi	50/60Hz±0,1%
To'lqin shakli	Sof sinus to'lqin
Maksimal samaradorlik (batareya rejimi)	>94%	>94%	>94%	>94%
Displey va aloqa
LCD displey	Ishlash rejimi/yuklash/kirish/chiqish va h.k.
Ishlash muhiti harorati	0~40 daraja
Ish muhitining namligi	20% ~ 95% (kondensatsiyalanmagan)
Saqlash harorati	-15~60 daraja
Shovqin	50 db dan kam yoki unga teng
Hajmi L * W * H (mm)	495312125
Og'irligi (KG)	9.5	9.5	12.5	21.5
